Biometrics 101
What are biometrics and how are they used?
Biometrics is the science and technology of authentication (i.e. establishing the identity of an individual) by measuring the person's physiological or behavioral features.
We specialize in biometric fingerprint recognition devices that identify a user's fingerprint ridge pattern to create a binary number which represents certain points in the pattern. With this information, a user's finger is scanned and the fingerprint pattered is detected and used for access control through a keyless door lock.
This biometric security keyless door lock system allows for complete keyless entry using only a fingerprint authentication.
Important Facts about the BioAxxis® BD1 Biometric Lock:
The BioAxxis® does not store an image of a users fingerprint!!
A person's fingerprint pattern cannot be recreated with data stored in the BD1.
All of our fingerprint door locks are rated for indoor and outdoor use
All of our biometric access control products use weather and static resistant optical sensor technologies
Satin Nickel (US15)
Polished Brass (US3)
Normal Price: $349
Sale Price:
$299.00
BioAxxis® BD1 Biometric Deadbolt
BD1 Super Sale: $50 off all models of the BioAxxis BD1 until Midnight on July 31, 2008!! Weatherproof fingerprint deadbolt for your home or office!The BioAxxis® BD1 biometric fingerprint deadbolt was designed right here in the United States by one of our strategic partners. The lock features a protective slide cover for the scanner, keeping it safe from the "elements". With the input of thousands of US consumers as well as multiple well-respected US locksmiths and security firms, we have created a deadbolt lock that truly accomplishes a unique blend of beauty and unparalleled security. In addition, we have secured the highest quality components for the BD1 to redefine the standard in the fingerprint lock market - ANSI-equivalent mechanics, 100% weatherproof construction and a solid steel deadbolt with case-hardened roller pin, to name a few. The BD1 is currently available in 3 stocked finishes. A satin / brush chrome, a polished brass finish and the oil-rubbed bronze. The BD1 is the first biometric dead bolt designed with a 5 pin Tumbler KW1 keyway, allowing you to replace the keycore and have more keys made for your lock. Allowing access to up to 30 users, this lock makes a great fit for all residential applications. Trust in the Quality and Security of a Biometric Finger Print Door LockThe BioAxxis BD1 fingerprint deadbolt is a great lock for both homes and small businesses. Its sleek design, available in three different finishes, helps it blend in with a room’s décor and add its own complimentary touch to the surroundings. Its sturdy construction and protective slide make it weatherproof and suitable for both indoor or outdoor use. The BioAxxis BD1 is great for locking up guns and valuables indoors or securing outbuildings on your property. Small business can use this biometric fingerprint deadbolt to secure equipment rooms or areas that contain important customer information. By using this lock, you maintain complete control over who has access to areas you want to protect. The BioAxxis biometric lock also provides you with a convenient solution to avoiding lost or stolen keys and PINs. It contains capacity for up to 30 different users, making it ideal for any home or small company. If you would like some more information on the BioAxxis BD1 biometric door lock, just fill out the form on the bottom of this page. We’ll be more than happy to answer any questions and provide you with the information you need to make your decision. When buying from FingerPrintDoorLocks.com, you can be confident in the quality and performance of the products you order from us. We offer you free technical support with your purchase and give you 30 days to return any item you’re not completely satisfied with. |
SEE MORE FINGERPRINT DOOR LOCKS HERE: Index Page
Ordering
* - In stock items ordered before 3PM EST will ship the same day (US Orders Only)! View the Terms and Conditions page for more information.
Features
- Five pin tumbler rekeyable KW1 keyway, as compared to most biometric locks with proprietary keyways. Can easily have keys made or the keyway replaced.
- Includes three nickel plated brass keys
- Solid brass cylinder plug
- One inch brass deadbolt with case-hardened steel roller pin to resist sawing, as compared to hollow tin deadbolts for most other biometric locks
- Each lock package includes one 60mm and one 70mm backset, as compared to more damage-prone adjustable backsets
- ANSI Grade 3 certified deadbolt
- Weatherproof - Fully resistant to rain, snow, temperature extremes, humidity, UV and dust. No other biometric deadbolt can make these claims
- Deadbolt is mounted internally through the door for better security, as opposed to externally on the door like many other biometric deadbolts
- Elegant and contemporary appearance
- Non-Handed - will fit any left or right handed door
- Additional security added with keyhole cover
- Up to 30 users (each user can scan fingerprint 2 times for total of 60 stored template)
- Sliding weather cover triggers sensor to power on automatically
- Sliding weather cover also triggers deadbolt to re-engage (no tricky buttons to push or PIN Codes to recall)
- Easy to install
- Easy to program and operate
- Battery operation with low battery alert - non-volatile memory will not delete stored fingerprints (even if batteries expire)
Includes
- BioAxxis® Biometric Deadbolt front and rear bodies
- All mounting hardware
- 3 manual override keys
- Manual and installation templates
Specifications
- Warranty Period
- 24 Month Replacement with 48 Month Option
- Fingerprint Sensor Type
- CMOS Optical - 500 dpi
- Number of Users
- 30
- Verification Type
- 1 to N
- Certifications
- CE & FCC
- Cylinder
- ANSI A156.5 2001,Grade 3
- Scanning Time
- <1 second for all 30 users
- False Acceptance Rate (FAR)
- < .0001%
- False Rejection Rate (FRR)
- < .01%
- Power Supply
- 4 AA size batteries
- Operating Temperature
- -30 F to 150 F
- Dimensions (L x W x D)
- 6" x 3" x 1.4"
- Weight
- 5 lbs
- Door Thickness Requirement
- 1 3/8" to 2"
- Door Requirement
- Wood or Metal
Documentation
Usage Guide
Home Use:
- With a biometric lock you can easily give your children or other family members access to your home without needing to worry about them losing the keys
- Unlike keyed locks, with the BD1 fingerprint deadbolt door lock there is no need to bring your keys with you when going for a run or a visit with the neighbor down the street
- Protect your family by locking up firearms and other harmful items - effectively converting a closet into a biometric vault
- Use the BioAxxis® BD1 Biometric deadbolt Lock to conveniently secure outbuildings such as pool houses and sheds for that added security.
Small Office Use:
- Secure server closets or equipment rooms using industry leading fingerprint recognition technology.
- Secure offices that contain customer's sensitive information with the convenience and biometric security of the BD1 fingerprint deadbolt lock.
- Allow users to access secure areas without keys, pin numbers or cards to remember.
